LED Curve TubE Side view - 120 Degrees

A flexible, simple LED linear lighting system made from durable PVC. It has multiple applications including architectural exteriors and interiors, commercial applications from signage to joinery, neon signage replacement and decorative sculptural elements. The side view tube has the illuminated face perpendicular to the bend.

Product Details

Application
Architectural exteriors and interiors
Commercial applications
i.e.Signage to joinery
Neon Signage replacement
Decorative Sculptural elements
Colour Temperature
2700K, 3000K, 4000K, 5500K
Materials
Anti-UV PVC - Ivory White
5050 SMD LEDs
IP Rating
IP68: Moulded cable end
IP67: Screwed end connectors

Technical Data

Input Power
24V DC
Watts (per metre)
12 Watts
Lumens (per metre)
2700K    306     lm
3000K    323.6  lm
4200K    306     lm
5500K    329.9  lm
Optics
120 Degrees
SMD LEDs
SMD5050
LEDs per metre
144 p/m
IK Class
IK08
Maximum Bend Diameter
8cm
Continuous Length
20m power at both ends
Minimum Cutting Length
10cm or
16.67cm (Orange and Red Tube Only)
Weight
.5 Kg/m
Dimming
Triac
1-10V
Dali
